| 3 | 48600811ST (replaces part #
48600569) | Adjuster compression cpl. | $4.83 | $4.11 | 10+ In-Stock | | |
| 12 | 48600693 | OUTER TUBE L577 D54/60MM 2L BL | $412.76 | $350.85 | Usually ships in 7-10 business days | | |
| 13 | 48600698 | Fork protection ring 62,1mm | 08 | $10.99 | $9.34 | 10+ In-Stock | | |
| 15 | 48601009 (replaces part #
48600429) | Guide bushing 48x52x12 | $14.18 | $12.05 | 10+ In-Stock | | |
| 16 | 48600013 | Supportwasher 50x57,6x1,5 | $3.62 | $3.08 | 10+ In-Stock | | |
| 17 | S604800001000C1 (replaces part #
48600347) | Shaft seal SKF 48x58x11,4 black | 03 | $16.05 | $13.64 | 10+ In-Stock | | |
| 18 | 48600070 | Snap ring SB58x1,5 acc drawing | $2.41 | $2.05 | 10+ In-Stock | | |
| 19 | S604800000000C1 (replaces part #
48600400) | Dirtscarper SKF 48mm black | D=48 | $15.06 | $12.80 | 10+ In-Stock | | |
| 22 | 48601008 (replaces part #
48600428) | Guide bushing 47x49x20 | $14.18 | $12.05 | 10+ In-Stock | | |
| 24 | 48600281 | Membrane 11,2x37x112 | $11.65 | $9.90 | 10+ In-Stock | | |
| 26 | 48600301 | O-ring 9,5x1,5 NBR70 yellow | $1.20 | $1.02 | 8 In-Stock | | |
| 27 | 46810811 | O-ring 17x2 70 Sh NBR black | $1.20 | $1.02 | 10+ In-Stock | | |
| 28 | 48600280S | SCREW BUSH M20X1 L=33 CPL. | L=33 | $71.05 | $60.39 | 8 In-Stock | | |
| 29 | 48600275 | Copper disc 20,5x26x1 | $2.41 | $2.05 | 10+ In-Stock | | |
| 30 | 48600269 | Adjustment tube 6x371 | L=371 | $25.29 | $21.50 | Usually ships in 7-10 business days | | |
| 31 | 48600464 | Piston rod 12x405 | 2005 | $161.99 | $161.99 | Usually ships in 7-10 business days | | |
| 32 | 48600459 | Lock nut M12x1 h23 WAF17 | $11.65 | $9.90 | Usually ships in 7-10 business days | | |
| 33 | 48600277 | Needle 4,5x43,6 | 07 | $6.48 | $5.51 | 10+ In-Stock | | |
| 34 | 48600298 | O-ring 2x1,5 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 35 | 48600444 | Spring (5,4) 4-23 rebound | C=4N/MM | $3.62 | $3.08 | 10+ In-Stock | | |
| 38 | 91410060S | SPRING 4,2 N/MM SET D=5,0MM | D=5,0MM;(As required) | $155.99 | $132.59 | Usually ships in 7-10 business days | | |
| 38 | 91410051S | POLISHED SPRING 4,2 N/MM2 CC | (As required) | $99.99 | $84.99 | Usually ships in 7-10 business days | | |
| 38 | 91410030S | SPRING 5,0 N/MM | (As required) | $171.59 | $145.85 | Usually ships in 7-10 business days | | |
| 38 | 91410059S | SPRING 4,0 N/MM SET | (As required) | $155.99 | $132.59 | Usually ships in 7-10 business days | | |
| 38 | 91410028S | SPRING 4,6 N/MM SET D=5,1MM | D=5,1MM;(As required) | $171.59 | $145.85 | Usually ships in 7-10 business days | | |
| 38 | 91410020S (replaces part #
91410029S) | SPRING 4,8N/MM SET D=5,25 MM | (As required) | $155.99 | $132.59 | 3 In-Stock | | |
| 38 | 91410027S | SPRING 4,4 N/MM SET D=5,1MM | D=5,1MM;(As required) | $153.09 | $130.13 | Usually ships in 7-10 business days | | |
| 38 | 91410052S | POLISHED SPRING 4,4 N/MM2 CC | (As required) | $103.99 | $88.39 | Usually ships in 7-10 business days | | |
| 39 | 48600458 | Washer 35x43x1,5 plastic | (As required) | $2.41 | $2.05 | 10+ In-Stock | | |
| 39 | 48600456 | Washer 35x43x2,5 plastic | (As required) | $2.41 | $2.05 | 10+ In-Stock | | |
| 39 | 48600457 | Preload bush 35x43x3,5 | (As required) | $2.41 | $2.05 | 10+ In-Stock | | |
| 40 | 48600525 | Spring retainer 12,3x19x1,25 rebound | $2.41 | $2.05 | 10+ In-Stock | | |
| 42 | 48600520 | Spring support ring 27,08x42x41 | $78.75 | $66.94 | Usually ships in 7-10 business days | | |
| 43 | 48600299 | O-ring 6x1,2 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 44 | 48600578 | Spring (13,9) 37-32 rebound | L=32 C=37 DI=13,9 | $10.95 | $9.31 | 7 In-Stock | | |
| 45 | 48600576 | Tap 6x46 rebound | $14.99 | $12.74 | 10+ In-Stock | | |
| 47 | 35480377 | Spring (11,7) 1,5-8 valve | D=0,5 | $2.41 | $2.05 | 10+ In-Stock | | |
| 47 | 48600382 | Spring (11,4) 0,4-8 valve | C=0,4 | $2.41 | $2.05 | 10+ In-Stock | | |
| 48 | 48600519S1 | MEMBRANE HOLDER INKL. PIN SET | $320.87 | $272.74 | Usually ships in 7-10 business days | | |
| 49 | 48600512 | Round-wire snap ring 28,5x1,5 | D=25,5 | $5.93 | $5.04 | 9 In-Stock | | |
| 50 | 48600542 | HS countersunk head screw M4x6 | $3.62 | $3.08 | 6 In-Stock | | |
| 51 | 46811499 | O-ring 21x2 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 52 | 48600047 | Piston 6x27,8x9 compression | D=27,9 | $11.54 | $9.81 | 10+ In-Stock | | |
| 53 | 50180222 | O-ring 4x1,5 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 54 | 48600518S | PIN VALVE SET | - | $8.00 | Not Shipping | | |
| 55 | 40540486 | Nut M6x0,5 h6,5 WAF10 rebound | $4.83 | $4.11 | 10+ In-Stock | | |
| 56 | 48600294 | GUIDE RING 44,2 X39,3 | $65.19 | $55.41 | Usually ships in 7-10 business days | | |
| 57 | 48600577 | Spring guide ring 27,08x32x9,5 | $6.48 | $5.51 | 9 In-Stock | | |
| 59 | 48600048 | O-ring 46x2 NBR70 siliconized yellow | $3.62 | $3.08 | 10+ In-Stock | | |
| 60 | 48600690S1 | AXLE CLAMP L/S + TUBE CPL. 08 | 08 | $494.88 | $420.65 | Usually ships in 7-10 business days | | |
| 61 | 48600691S1 | AXLE CLAMP R/S + TUBE CPL. | 08 | - | $395.90 | Usually ships in 7-10 business days | | |
| 62 | 0025080256 (replaces part #
0015080253) | HH collar screw M8x25 | WS=10 | $2.41 | $2.05 | 10+ In-Stock | | |
| 63 | 48600163 | Nut valve M6x0,5 h6,5 WAF17 | D=2 | $3.62 | $3.08 | 10+ In-Stock | | |
| 64 | 48600202 | Spring (8,5) l6,5 valve | D=0,7 | $2.41 | $2.05 | 10+ In-Stock | | |
| 69 | 48600509 | Tap 6x38 compression | $12.20 | $10.37 | 5 In-Stock | | |
| 71 | 48600575 | Piston 6,07x22,7x13 | 2007 | $17.37 | $14.76 | 10+ In-Stock | | |
| 72 | 48601625 (replaces part #
48600455) | Piston ring 21x23x5 | $5.29 | $4.50 | 10+ In-Stock | | |
| 74 | 48600296 | RING D=23,45X2,65 | D=23,45X2,65 | $12.06 | $10.25 | Usually ships in 7-10 business days | | |
| 75 | 48600829 (replaces part #
48600471) | Seal ring Freudenberg 12mm 85Sh violett | $7.14 | $6.07 | 10+ In-Stock | | |
| 76 | 48600546S | SCREW SLEEVE M24,5X1 CPL. | $82.20 | $69.87 | Usually ships in 7-10 business days | | |
| 77 | 48600430 | Guide bushing 12x14x10 | $7.58 | $6.44 | 10+ In-Stock | | |
| 78 | 48600709 | Check valve locking R4 | $21.22 | $18.04 | Usually ships in 7-10 business days | | |
| 79 | 48600446 | Round-wire snap ring 24x2 | D=20 | $2.41 | $2.05 | 6 In-Stock | | |
| 81 | 15080017 | Silicon plug 60Sh | $6.15 | $5.23 | 10+ In-Stock | | |
| 82 | 48600692 | Rubber cap 26,4x11 | D=26,4 | $3.62 | $3.08 | 10+ In-Stock | | |
| 83 | 48601166S1 (replaces part #
48600401S1) | Fork Fluid Viscosity 4.0 5L | 2005 | $175.99 | $149.59 | 10+ In-Stock | | |
| 84 | 40140024 | O-ring 43x2 NBR70 siliconized yellow | $4.83 | $4.11 | 10+ In-Stock | | |
| 85 | 48600516E1 (replaces part #
48600516S1) | SCREW CAP L=125 | L=125 | $126.71 | $107.70 | 5 In-Stock | | |
| 86 | 48600527 | HS countersunk head screw M4x16 DIN 7991 | $2.41 | $2.05 | 9 In-Stock | | |
| 87 | 48600526 | Cross flat head screw M4x10 | $2.41 | $2.05 | 10+ In-Stock | | |
| 88 | 48600514 | Clamping ring bladder 11,31x22x7,5 | $32.44 | $27.57 | 4 In-Stock | | |
| 98 | T14034 (replaces part #
T511) | Fuchs grease IPR (250g) | $40.69 | $34.59 | 10+ In-Stock | | |
| 99 | RP10046T (replaces part #
R14014) | Fork service kit 48mm | $124.95 | $106.21 | 10+ In-Stock | | |
