| 3 | 48600812ST (replaces part #
48600812S) | ADJUSTING KNOB + SCREW | $6.15 | $5.23 | 10+ In-Stock | | |
| 4 | 48600481 | Cross countersunk head screw M4x8 | $2.41 | $2.05 | 10+ In-Stock | | |
| 5 | 48600046 | O-ring 3x1,5 NBR70 | $1.99 | $1.69 | 10+ In-Stock | | |
| 6 | 46810340 | O-ring 45x2 NBR70 siliconized | $1.20 | $1.02 | 10+ In-Stock | | |
| 12 | 48600736 | Fork outer tube 49,13x577 dt54 db60 natu | $543.94 | $462.35 | Usually ships in 7-10 business days | | |
| 13 | 48600698 | Fork protection ring 62,1mm | 08 | $10.99 | $9.34 | 10+ In-Stock | | |
| 15 | 48601009 | Guide bushing 48x52x12 | $14.18 | $12.05 | 10+ In-Stock | | |
| 16 | 48600013 | Supportwasher 50x57,6x1,5 | $3.62 | $3.08 | 10+ In-Stock | | |
| 17 | S604800001000C1 (replaces part #
48600969) | Shaft seal SKF 48x58x11,4 black | $16.05 | $13.64 | 10+ In-Stock | | |
| 18 | 48600070 | Snap ring SB58x1,5 acc drawing | $2.41 | $2.05 | 10+ In-Stock | | |
| 19 | S604800000000C1 (replaces part #
48600968) | Dirtscarper SKF 48mm black | $15.06 | $12.80 | 10+ In-Stock | | |
| 22 | 48601008 | Guide bushing 47x49x20 | $14.18 | $12.05 | 10+ In-Stock | | |
| 24 | 48600557S | Stop 12,4x31,9x200 cpl. | $48.79 | $41.47 | 4 In-Stock | | |
| 30 | 48600559 | Adjustment tube 6x520 | 07 | $15.94 | $13.55 | 1 In-Stock | | |
| 31 | 48600568 | Piston rod 12x554 | $116.70 | $99.20 | 10+ In-Stock | | |
| 33 | 48600277 | Needle 4,5x43,6 | 07 | $6.48 | $5.51 | 10+ In-Stock | | |
| 34 | 48600298 | O-ring 2x1,5 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 35 | 48600444 | Spring (5,4) 4-23 rebound | $3.62 | $3.08 | 10+ In-Stock | | |
| 36 | 48600113 | Washer 32x42x2,5 plastic | $13.08 | $11.12 | 5 In-Stock | | |
| 38 | 91410015S | SPRING 4,4N/MM SET D=5,1MM | (As Required) | $171.59 | $145.85 | 2 In-Stock | | |
| 38 | 91410016S | SPRING 4,6N/MM SET | (As Required) | $171.59 | $145.85 | 3 In-Stock | | |
| 38 | 91410012S | SPRING 3,8N/MM SET D=4,9MM | (As Required) | $171.59 | $145.85 | Usually ships in 7-10 business days | | |
| 38 | 91410013S | SPRING 4,0N/MM SET D=5,0MM | (As Required) | $266.69 | $226.69 | Usually ships in 7-10 business days | | |
| 38 | 91410014S | SPRING 4,2N/MM SET D=5,0MM | (As Required) | $155.99 | $132.59 | Usually ships in 7-10 business days | | |
| 39 | 48600021 | Spring retainer 33,5x43x3 | $19.68 | $16.73 | 10+ In-Stock | | |
| 40 | 48600525 | Spring retainer 12,3x19x1,25 rebound | $2.41 | $2.05 | 10+ In-Stock | | |
| 42 | 48600830S | SCREW SLEEVE M27X0,8 | $38.69 | $32.89 | Not Shipping | | |
| 43 | 48600299 | O-ring 6x1,2 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 44 | 48600511S (replaces part #
48600511) | Spring (13,9) 17-32 rebound cpl. | $3.29 | $2.80 | 10+ In-Stock | | |
| 45 | 48600576 | Tap 6x46 rebound | $14.99 | $12.74 | 10+ In-Stock | | |
| 47 | 48600382 | Spring (11,4) 0,4-8 valve | $2.41 | $2.05 | 10+ In-Stock | | |
| 51 | 48601625 (replaces part #
48600455) | Piston ring 21x23x5 | $5.29 | $4.50 | 10+ In-Stock | | |
| 52 | 48600575 | Piston 6,07x22,7x13 | 2007 | $17.37 | $14.76 | 10+ In-Stock | | |
| 55 | 40540486 | Nut M6x0,5 h6,5 WAF10 rebound | $4.83 | $4.11 | 10+ In-Stock | | |
| 57 | 48600764 | Adapter 23x28x70 | $26.28 | $22.34 | Usually ships in 7-10 business days | | |
| 58 | 48600763 | Tube 23x350 | 09 | $88.21 | $74.98 | 8 In-Stock | | |
| 59 | 48600048 | O-ring 46x2 NBR70 siliconized yellow | $3.62 | $3.08 | 10+ In-Stock | | |
| 60 | 48600860SA2 (replaces part #
48600860SA) | AXLE CLAMP L/S + TUBE CPL. | $764.16 | $649.54 | Usually ships in 7-10 business days | | |
| 61 | 48600861S1 | AXLE CLAMP R/S + TUBE CPL. 09 | 09 | $680.49 | $578.42 | 3 In-Stock | | |
| 62 | 0025080256 | HH collar screw M8x25 | TX40 | $2.41 | $2.05 | 10+ In-Stock | | |
| 63 | 48600163 | Nut valve M6x0,5 h6,5 WAF17 | D=2 | $3.62 | $3.08 | 10+ In-Stock | | |
| 64 | 48600202 | Spring (8,5) l6,5 valve | $2.41 | $2.05 | 10+ In-Stock | | |
| 69 | 48600586S3 (replaces part #
48600586S) | Compression | 07 | $44.32 | $37.67 | 10+ In-Stock | | |
| 71 | 48600047 | Piston 6x27,8x9 compression | $11.54 | $9.81 | 10+ In-Stock | | |
| 72 | 46811499 | O-ring 21x2 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 73 | 35480320 | O-ring 24x2 NBR70 | $1.20 | $1.02 | 10+ In-Stock | | |
| 81 | 48600004 | Copper disc 29,5x33,5x1 | $4.83 | $4.11 | 10+ In-Stock | | |
| 82 | 48600141 | Rubber cap 35x10 NBR80 | $4.83 | $4.11 | 10+ In-Stock | | |
| 83 | 48601166S1 (replaces part #
48600765S1) | Fork Fluid Viscosity 4.0 5L | 2008 | $175.99 | $149.59 | 10+ In-Stock | | |
| 85 | 48600431E2 (replaces part #
48600431S2) | Screw cap M51x1,5 cpl. | 09 | $150.58 | $127.99 | Usually ships in 7-10 business days | | |
| 86 | 48600053 | Preload bush 26,5x42x1,5 | (As Required) | $4.83 | $4.11 | 10+ In-Stock | | |
| 86 | 48600037 | Preload bush 26,5x42x5 | (As Required) | $4.83 | $4.11 | 10+ In-Stock | | |
| 86 | 48600038 | Preload bush 26,5x42x10 | (As Required) | $3.62 | $3.08 | 10+ In-Stock | | |
| 86 | 48600036 | Preload bush 42x26,5x2,5 | (As Required) | $2.41 | $2.05 | 10+ In-Stock | | |
| 98 | T14034 (replaces part #
T511) | Fuchs grease IPR (250g) | $40.69 | $34.59 | 10+ In-Stock | | |
| 99 | RP10046T (replaces part #
R14020) | Fork service kit 48mm | $124.95 | $106.21 | 10+ In-Stock | | |
