2013 Yamaha FJR1300A Electrical 1 OEM Parts Diagram

Tag	Part #	Description	MSRP	Our Price	Stock Status
1	5PS-82501-21-00 (replaces part # 5PS-82501-20-00)	MAIN SWITCH STEERING LOCK	$228.99	$178.61	Usually ships in 7-10 business days
2	4BH-82511-09-00	BLANK KEY \| AP	$33.99	$26.51	7 In-Stock
3	90109-08196-00 (replaces part # 90109-08195-00)	BOLT	$9.49	$7.40	10+ In-Stock
4	1MC-8591A-21-00 (replaces part # 1MC-8591A-20-00)	ENGINE CONTROL UNIT	$1,466.99	$1,266.34	Usually ships in 7-10 business days
5	1MC-82310-00-00	IGNITION COIL ASSY	$134.99	$105.29	Usually ships in 7-10 business days
6	1MC-82540-01-00 (replaces part # 1MC-82540-00-00)	NEUTRAL SWITCH ASSY	$143.99	$112.31	Usually ships in 7-10 business days
7	93210-21001-00	O-RING	$6.49	$5.06	10+ In-Stock
8	90154-05046-00 (replaces part # 90154-05073-00)	SCREW, BINDING	$2.45	$2.11	4 In-Stock
9	1UA-82591-00-00	BAND	$5.49	$4.28	10+ In-Stock
10	1MC-85720-01-00 (replaces part # 1MC-85720-00-00)	OIL LEVEL GAUGE ASSY	$132.99	$103.73	Usually ships in 7-10 business days
11	4XV-8A8E0-00-00	O-RING	$15.49	$12.70	Usually ships in 7-10 business days
12	95022-06016-00	BOLT, FLANGE	$3.90	$3.35	10+ In-Stock
13	5YP-85790-00-00	THERMOSENSOR ASSY	$70.99	$55.37	10+ In-Stock
14	90201-12790-00	WASHER, PLATE	$10.49	$8.18	5 In-Stock
15	1MC-81673-00-00	ROTOR	$39.99	$32.79	Usually ships in 7-10 business days
16	90105-10153-00	BOLT, FLANGE	$6.49	$5.84	Usually ships in 7-10 business days
17	90201-10065-00	WASHER, PLATE	$2.45	$2.20	Usually ships in 7-10 business days
18	1MC-85896-01-00 (replaces part # 1MC-85896-00-00)	SENSOR, CAM POSITION	$111.99	$87.35	Usually ships in 7-10 business days
19	4D9-81168-00-00	O-RING	$7.49	$5.84	5 In-Stock
20	91317-06016-00 (replaces part # 90110-06193-00)	BOLT (4MY)	-	$1.42	10+ In-Stock
21	3P6-81670-00-00	PICK-UP ASSY	$133.99	$104.51	Usually ships in 7-10 business days
22	90465-08055-00	CLAMP	$4.00	$3.60	Usually ships in 7-10 business days
23	91317-05012-00 (replaces part # 90110-05032-00)	BOLT	$2.75	$2.36	10+ In-Stock
