2019 Yamaha YZ250X Starter OEM Parts Diagram

Tag	Part #	Description	MSRP	Our Price	Stock Status
1	5NX-15601-10-00	KICK SHAFT ASSY	$319.99	$249.59	10+ In-Stock
2	90201-20685-00	WASHER, PLATE (T=0.5)	$8.49	$6.62	1 In-Stock
3	93410-20038-00	CIRCLIP, S-TYPE	$4.05	$3.48	10+ In-Stock
4	4GY-15671-00-00	WHEEL, RATCHET	$97.99	$76.43	2 In-Stock
5	90501-16016-00	SPRING, COMPRESSION	$6.49	$5.06	2 In-Stock
6	90201-167P7-00	WASHER, PLATE	$10.49	$8.60	Usually ships in 7-10 business days
7	99009-16400-00	CIRCLIP	$6.49	$5.06	4 In-Stock
8	5NL-15664-00-00	GUIDE, SPRING	$14.49	$11.30	1 In-Stock
9	90508-30743-00	SPRING, TORSION	$20.99	$16.37	1 In-Stock
10	90201-162H4-00	WASHER, PLATE	$10.49	$8.18	8 In-Stock
11	2NX-15674-00-00 (replaces part # 214-15674-00-00)	GUIDE, RATCHET WHEEL	$10.99	$8.57	2 In-Stock
12	214-15686-00-00	WASHER, LOCK	$8.49	$6.62	7 In-Stock
13	97D95-06016-00 (replaces part # 97022-06016-00)	BOLT, HEXAGON DEEP R	$2.76	$2.37	10+ In-Stock
14	5CU-15651-00-00	GEAR, KICK IDLE	$139.99	$109.19	Usually ships in 7-10 business days
15	90201-20276-00	WASHER, PLATE (T=1.0)	$9.49	$7.40	10+ In-Stock
16	99009-20400-00	CIRCLIP	$9.49	$7.40	10+ In-Stock
17	93102-18278-00	OIL SEAL	$13.49	$10.52	10+ In-Stock
18	5NX-15620-20-00	KICK CRANK ASSY	$235.99	$184.07	4 In-Stock
	AFTERMARKET ALTERNATIVE	$134.99	$74.99	10+ In-Stock
19	5NX-15621-10-00	BOSS, KICK CRANK	$86.99	$67.85	Usually ships in 7-10 business days
20	90501-147A5-00	SPRING, COMPRESSION	$9.49	$7.40	10+ In-Stock
21	93507-32031-00 (replaces part # 93507-32009-00)	BALL	$5.49	$4.28	10+ In-Stock
22	90151-06045-00	SCREW, COUNTERSUNK	$9.49	$7.40	10+ In-Stock
23	93210-17570-00	O-RING	$8.49	$6.62	7 In-Stock
24	90110-08052-00	BOLT, HEXAGON SOCKET HEAD	$9.49	$7.40	10+ In-Stock
25	90201-08048-00	WASHER, PLATE	$6.49	$5.06	10+ In-Stock
