2004 Yamaha V-Star Silverado XVS1100 Windshield Saddlebags Backrest OEM Parts Diagram

Tag	Part #	Description	MSRP	Our Price	Stock Status
1	STR-5KS03-10-01	03 V STAR SILVER WINDSHIELD \| NOT SHOWN	$401.99	$334.14	Usually ships in 7-10 business days
2	STR-5KS03-40-02	WINDSHIELD MOUNTS \| NOT SHOWN	$120.99	$98.14	Usually ships in 7-10 business days
3	STR-5VN73-02-00 (replaces part # STR-5GA73-02-00)	SADDLEBAG SET, STUDDED \| NOT SHOWN	$848.95	$742.11	Usually ships in 7-10 business days
4	STR-5BN41-50-02	BACKREST PAD \| NOT SHOWN	$49.95	$41.74	Usually ships in 7-10 business days
5	5KS-24710-10-00	SINGLE SEAT ASSY \| NOT SHOWN	$359.99	$299.26	Usually ships in 7-10 business days
6	5KS-24750-41-00 (replaces part # 5KS-24750-10-00)	TANDEM SEAT ASSY \| NOT SHOWN	$273.99	$227.48	Usually ships in 7-10 business days
7	449-85131-20-00	REFLECTOR, REAR 1 \| NOT SHOWN	$0.00	$0.00	Not Shipping
8	90201-05029-00	WASHER, PLATE \| NOT SHOWN	$9.49	$7.40	10+ In-Stock
9	90176-05001-00	NUT, CROWN \| NOT SHOWN	$8.49	$7.64	Usually ships in 7-10 business days
10	5VP-F8430-00-00 (replaces part # STR-5VN73-02-A0)	SADDLEBAG COMP. 1 \| NOT SHOWN	$429.49	$366.08	Usually ships in 7-10 business days
11	STR-5VN73-02-B0	SADDLEBAG, RIGHT \| NOT SHOWN	$384.49	$347.92	Not Shipping

1

03 V STAR SILVER WINDSHIELD | NOT SHOWN

$401.99

$334.14

Usually ships in 7-10 business days

3

(replaces part #
STR-5GA73-02-00)

SADDLEBAG SET, STUDDED | NOT SHOWN

$848.95

$742.11

Usually ships in 7-10 business days

5

SINGLE SEAT ASSY | NOT SHOWN

$359.99

$299.26

Usually ships in 7-10 business days

7

449-85131-20-00

REFLECTOR, REAR 1 | NOT SHOWN

$0.00

Not Shipping

9

NUT, CROWN | NOT SHOWN

$8.49

$7.64

Usually ships in 7-10 business days

11

STR-5VN73-02-B0

SADDLEBAG, RIGHT | NOT SHOWN

$384.49

$347.92

Not Shipping
