2020 Yamaha RAPTOR 700R Electrical 2 OEM Parts Diagram

Submodel RAPTOR 700R SE - YFM70RSSLM - 2020

Shop Aftermarket Parts

TO VIEW YAMAHA OEM PARTS, PLEASE SIGN IN

Important message:

Please correct the information below:

Existing Account:



Forgot your password? Click Here.

Quick Log In:



Note: Password must be at least 6 characters in length and is case sensitive.


PLEASE SELECT A SUBMODEL

Some OEM parts vary between different machine specifications and paint schemes.
Choose your machine's submodel to help with fitment.

Submodels
Placeholder
SELECT MACHINE

ELECTRICAL 2

OEM Assembly Image

Click and drag to reposition image. Use mouse wheel to zoom in and out.

Shipping Notice
⚠ WARNING: Cancer and Reproductive Harm -

Get additional RM Cash on OEM purchases!

Select parts to add, then click
TagPart #DescriptionMSRPOur PriceStock StatusQtyAdd?
13Y6-85130-02-00REAR REFLECTOR ASSY$30.99$24.173 In-Stock
292990-05200-00

(replaces part #
92902-05200-00)

WASHER, PLAIN$5.49$4.2810+ In-Stock
395380-05600-00

(replaces part #
95302-05600-00)

NUT$9.49$8.54Usually ships in 7-10 business days
4449-85131-02-00REFLECTOR, REAR 1$33.99$26.514 In-Stock
592990-05200-00

(replaces part #
92902-05200-00)

WASHER, PLAIN$5.49$4.2810+ In-Stock
692990-05100-00

(replaces part #
92902-05100-00)

WASHER, SPRING-$0.8310+ In-Stock
72LS-H5112-00-00BRACKET, REFLECTOR$32.99$27.05Usually ships in 7-10 business days
82EK-85111-00-00REFLECTOR, FRONT 1$31.99$24.951 In-Stock
992990-05200-00

(replaces part #
92902-05200-00)

WASHER, PLAIN$5.49$4.2810+ In-Stock
1095380-05600-00

(replaces part #
95302-05600-00)

NUT$9.49$8.54Usually ships in 7-10 business days
