1982 Yamaha XT125 Starter OEM Parts Diagram

Submodel XT125J - 1982

Shop Aftermarket Parts

TO VIEW YAMAHA OEM PARTS, PLEASE SIGN IN

Important message:

Please correct the information below:

Existing Account:



Forgot your password? Click Here.

Quick Log In:



Note: Password must be at least 6 characters in length and is case sensitive.


PLEASE SELECT A SUBMODEL

Some OEM parts vary between different machine specifications and paint schemes.
Choose your machine's submodel to help with fitment.

Submodels
Placeholder
SELECT MACHINE

STARTER

OEM Assembly Image

Click and drag to reposition image. Use mouse wheel to zoom in and out.

Shipping Notice
⚠ WARNING: Cancer and Reproductive Harm -

Get additional RM Cash on OEM purchases!

Select parts to add, then click
TagPart #DescriptionMSRPOur PriceStock StatusQtyAdd?
115A-15660-01-00KICK AXLE ASSEMBLY$145.99$113.87Usually ships in 7-10 business days
290468-26122-00CLIP$9.49$7.404 In-Stock
3401-15676-00-00COVER, SPRING$8.49$6.624 In-Stock
415A-15666-00-00SPACER$8.49$6.623 In-Stock
590508-26538-00SPRING, TORSION$13.49$10.523 In-Stock
693440-17138-00CIRCLIP$10.49$8.60Usually ships in 7-10 business days
790201-175F6-00WASHER, PLATE$11.49$8.963 In-Stock
836X-15641-00-00GEAR, KICK$77.99$60.83Usually ships in 7-10 business days
990209-17226-00WASHER$10.49$8.184 In-Stock
1093102-17263-00OIL SEAL$11.49$8.9610+ In-Stock
1190201-173F4-00WASHER, PLATE$9.49$8.54Usually ships in 7-10 business days
1215A-15651-01-00GEAR, KICK IDLE (28T)$73.99$57.71Usually ships in 7-10 business days
1390214-17028-00WASHER, CLAW$9.49$8.54Usually ships in 7-10 business days
1499009-17400-00CIRCLIP$5.49$4.2810+ In-Stock
1515A-15620-01-00

(replaces part #
15A-15620-00-00)

KICK CRANK ASSY$123.99$96.71Not Shipping
1615A-15621-02-00BOSS, KICK CRANK$144.99$113.09Not Shipping
1790501-12081-00SPRING, BOSS STOPPER$9.49$7.4010+ In-Stock
1893507-32031-00BALL$5.49$4.2810+ In-Stock
1990152-06010-00

(replaces part #
90157-06048-00)

SCREW, COUNTERSUNK$10.49$8.1810+ In-Stock
2097013-08030-00

(replaces part #
97313-08030-00)

BOLT$3.80$3.2710+ In-Stock
